FDM Titan and Vantage

FDM Titan

The Stratasys FDM Vantage™ 3D printer incorporates the latest in innovative technologies to provide you with precise prototypes from a CAD design. Stratasys’ Fused Deposition Modeling (FDM) technology provides prototype parts, including internal features, that can be used to field-test form, fit, and function.

The Stratasys FDM Vantage 3D printer comes in four models with the following build envelope sizes:

  • Vantage I (initial) 14 x 10 x 10 in (355 x 254 x 254 mm)
  • Vantage X (Xa and Xp) 14 x 10 x 10 in (355 x 254 x 254 mm)
  • Vantage S (speed) 14 x 10 x 10 in (355 x 254 x 254 mm)
  • Vantage SE (speed + envelope) 16 x 14 x 16 in (406 x 355 x 406 mm)

The Stratasys FDM Titan™ 3D printer incorporates the latest in innovative technologies to provide you with precise prototypes from a CAD design. Stratasys’ Fused Deposition Modeling (FDM) technology provides prototype parts, including internal features, that can be used to test form, fit, and function.

The Stratasys FDM Titan™ 3D printer’s high-capacity oven has a build envelope of 16 x 14 x 16 in. (406 x 355 x 406 mm).

To view information about Stratasys FDM Legacy platforms (no longer manufactured), click here.

    AC Power Requirements

  • 46 Hz to 65 Hz
  • 230 VAC
  • 20 A

    LAN Requirements

  • Required for data transfer.
  • 100 base T, Ethernet protocol, RJ45 connector.
  • Static IP address.
